用途與特點：
◆氣動隔膜泵供墨；
◆傳動齒輪采用循環潤滑供油系統減低噪音，延長齒輪工作壽命，同時提高套色準確度。
◆設有自動剎車機構，機組分離后，剎車機構鎖緊周向位移，保持印刷機位。
◆本機有單色、雙色、三色、四色可供用戶選擇。
◆45#鋼高頻精磨齒輪，印刷更精確，效果更清晰。
◆本機膠軸網紋采用廣東著名廠家生產。
◆配變頻主動電機，起步穩，低噪音，節電可達25%。
Features:
◆Device ink from pneumatic Diaphragm.
◆Gear transmission uses circulating lubrication oil supply system to minimize noise and extend service life of gear and improve the precision of chromatic printing.
◆With automatic braking mechanish when the fight crew separate the brake locking keep printed seats.
◆The machine has single-color,double-color,three-colorand four-color available for option.
◆Main gear driving adopts 45# good steel to make.And gear to quench to deal.
◆The rubber-axis, reticulate, and other components used in machine are well-known manufacturers in Guangdong.
◆Frequency adjustment of motor starting stability,low noise,energy saving 25%.
技術參數 Technological Parameter:
|
型號Model
|
滾筒直徑
Roller diameter
|
過紙寬度
Over the paper width
|
有效印刷面積(mm2)
Area of valid printing
|
整機重量(約kg)
Whole machine weight
|
電機功率
Elecdtrical power
|
|
TS-1900
|
800
|
1800
|
2500×1600
|
7500
|
7.5
|
|
TS-2100
|
800
|
2000
|
2500×1800
|
8000
|
7.5
|
|
TS-1900
|
908
|
1800
|
2850×1600
|
8500
|
10
|
|
TS-2100
|
908
|
2000
|
2850×1800
|
9000
|
10
|
本印刷機型號由1900到3000均可定做。 This printing machine model number be arrived by 1900 to 3000 all can make to order. |
